| Main Specifications | |
| Projection Technology | 3LCD |
| Standard Resolution | WUXGA |
| Light Source | Laser |
| Brightness (TYP) | 16000lm |
| Throw Ratio (optional lens) | 1.24-2.01（STD） |
| 0.53-0.65 (Optional) | |
| 0.65-0.87 (Optional) | |
| 0.86-1.25 (Optional) | |
| 1.98-3.95 (Optional) | |
| 3.95-7.51 (Optional) | |
| Lens Shift | Yes |
| Power Range | AC100~240V |
| Operating Altitude | Below 3050m |
| Operating Temperature | 0℃~50℃ |
| Dimensions(W * D * H)(mm) | 599*240.2*493.8 |
| Net Weight(kg) | 28.9kg |
| Accessories | Power cable/Remote control/Batteries |
| Interface Parameters | |
| VGA IN | *1 |
| HDMI IN | *2 |
| USB-A | *1 |
| USB-B | *1(Display) |
| RJ45 | *1(Display) |
| HDBaseT | *1 |
| Audio in | *1 |
| VGA OUT | N/A |
| Audio out | *1 |
| RS232 | *1 |
| RJ45 | *1(Control) |
| USB-B | *1 (Upgrade) |
| HD-SDI | *1(Optional) |
| DVI-D | *1 |
| DMX512 | *1 |
| HDMI OUT | *1 |
