| Main Specifications | |
| Projection Technology | 3LCD |
| Standard Resolution | WUXGA /WXGA/XGA |
| Light Source | Lamp |
| Brightness | 3300-4600lm |
| Throw Ratio | 1.48-1.78 |
| 1.34-2.22 | |
| 1.26-2.09 | |
| 1.37-1.65 | |
| Lens Shift | N/A |
| Power Range | AC100~240V |
| Operating Altitude | Below 3000m |
| Operating Temperature | 0℃~40℃ |
| Dimensions(W * D * H)(mm) | 442*386*195 |
| Net Weight(kg) | 3.1-3.4kg |
| Accessories | Power cable/Remote control/Batteries/VGA cable/Quick start guide |
| Interface Parameters | |
| VGA IN | *1 |
| HDMI IN | *2 |
| USB-A | *1 |
| USB-B | *1(Display) |
| RJ45 | *1(Display) |
| Audio in | *1 |
| Audio out | *1 |
| RS232 | *1 |
| RJ45 | *1(Control) |
